SPECIFICATIONS
Nominal Basket Diameter 12", 305 mm
Nominal Impedance* 8 Ω
Power Handling 150 Watt RMS
Resonance 97 Hz
Usable Frequency Range 70 Hz - 4 kHz
Sensitivity* 102 dB
Magnet Weight 59 oz.
Gap Height 0.312", 7.9 mm
Voice Coil Diameter 2", 51 mm
THIELE & SMALL PARAMETERS
Resonant Frequency (fs) 97 Hz
DC Resistance (Re) 6.92 Ω
Coil Inductance (Le) 0.42m H
Mechanical Q (Qms) 14.43
Electromagnetic Q (Qes) 0.55
Total Q (Qts) 0.53
Compliance Equivalent Volume (Vas) 41.3 liters / 1.46 cu.ft.
Peak Diaphragm Displacement Volume (Vd) 42.6 cc
Mechanical Compliance of Suspension (Cms) 0.1 mm/N
BL Product (BL) 14.2 T-M
Diaphragm Mass Inc. Airload (MMs) 26 grams
Efficiency Bandwidth Product (EBP) 177
Maximum Linear Excursion (Xmax) 0.8 mm
Surface Area of Cone (Sd) 532.4 cm2
Maximum Mechanical Limit (Xlim) N/A
MOUNTING INFORMATION
Recommended Enclosure Volume
Sealed Acceptable
Vented Acceptable
Driver Volume Displaced 0.079 cu.ft. / 2.25 liters
Overall Diameter 12.03", 305.6 mm
Baffle Hole Diameter 11.07", 281.2 mm
Front Sealing Gasket Yes
Rear Sealing Gasket Yes
Mounting Holes Diameter 0.25", 6.4mm
Mounting Holes B.C.D. 11.59", 294.4mm
Depth 5.2", 132.1 mm
Net Weight 11.1 lbs, 5.03 kg
Shipping Weight 12.8 lbs, 5.81 kgs
MATERIALS OF CONSTRUCTION
Coil Construction Copper voice coil
Coil Former Polyimide former
Magnet Composition Ferrite magnet
Core Details Non-vented core
Basket Materials Pressed steel basket
Cone Composition Paper cone
Cone Edge Composition Paper cone edge
Dust Cap Composition Zurette dust cap
